Logic TRM120 User Manual

22
Item
Part Number
Description
01
TRM120-01A Mower Deck
02
TRM120-14 Rear Deflector Flap
03
FRP06014 Rivet Mono 6.5mm X 14mm (2mm X 9.5mm Panel)
04
FSH12035 S/Screw Hex Head M12 X 35
05
TRM120
-09L Rear Discharge Deflector L/H
05
TRM120-09R Rear Discharge Deflector R/H
06
TRM120
-22 Rear Clamping Plate
07
S216-1013 Self Locking Nut
08
S216-1012 Blade (Lg412)
09
S216-1026 Spindle
10
LRM120-41 Key Outer Pulley
11
S216-1025 Bearing Cover
12
FSH10030,FWF10,FNN10 S/Screw M10 X 30, Flat Washers, Nyloc Nut
13
MF120-1048 Bearing
14
TA102-03 Grease Nipple
15
S216-1024 Hub
16
S216-1023 Spacer
17
FSH10025,FWF10,FNN10 S/Screw M10 X 25, Flat Washers, Nyloc Nut
18
TRM120-23 Clamp plate front Outer
19
TRM120-12 Deflector front Flap: End
20
TRM120-13 Deflector front Flap: Centre
21
TRM120-24 Clamp plate front Centre
22
FSH08025,FWF08,FNN08 S/Screw M8 X 25, Flat Washers, Nyloc Nut
23
WP05,FRP03010 Manufacturers Plate Universal, Rivet Pop 1/8 X 3/8
24
WS01 Sticker: Logic – 240 X 75 MM
25
WS146 Sticker: Mower Hazard Sticker
26
WS147 Sticker: TRM120
27
S215-096 Sprocket Spacer Bush 2 MM
28
S215-091 Castor Bottom Collar 12 MM
29
S215-092 Castor Bush 6 MM
30
LRM120-38 Pulley Single V ‘B; Section 4”
31
S216-1027 Washer
32
S216-1015 Self Locking Ring Nut
33
FBH716200 Bolt Hex Head 7/16 UNF X 2”
34
LRM123-01 Top Hat Washer
35
TRM120-39 2 Vee Centrifugal Clutch (Purple Springs)
36
LRM123-04 Clutch Spacer 12 MM
37
LRM120-39 Pulley Double V ‘B’ Section 4”
38
WS36 Sticker: Design Right
39
WS64
Sticker: Ser No: N/Plate 50.4 X 19.1
40
MF120
-1054 Dust Cap
41
FSH10025,FWS
10
FWR10030
S/Screw M10 X 25, Spring Washer, Repair –
Washer
42
MF120
-1048 Outer Wheel Bearing
43
WT142 WL/TY 16 X 650 – 8 Kingstyre
