Logic TRM120 User Manual

23
Item
Part Number
Description
43
WT210
WL/TY 20 X 700 – 8 Carlisle/Max 4
44
MF120-1063 Spacer
45
TRM120-20A Guard Rail
46
FSH08030,FWF08,FNN08 S/Screw M8 X 30, Flat Washers, Nyloc Nut
47
TRM120-37 Spring Tension 5.38 MM Dia
48
TRM120
-25LA Axle L/H
48
TRM120
-25RA Axle R/H
49
TRM120-10 Wheel Arm Locking Pin
50
MSU
-S100 Sleeve Flat Grey 31.75 MM X 9.5
51
FSH12035,FWF12,FNN12 S/Screw M12 X 35, Flat Washers, Nyloc Nut
52
TRM120-02LA Height Adjuster Bracket Assembly L/H
52
TRM120-02RA Height Adjuster Bracket Assembly R/H
53
FCG03064 Clip R3 X 64 MM
54
FNN20 Nut Nyloc M20
55
LRM123-05 Belt V BX49
56
FBH16090,FWF16,FNN16 Bolt M16 X 90, Flat Washers, Nyloc Nut
57
TRM120-05A Drawbar Mounting Assembly
58
MFG104-15 Turnbuckle
59
TRM120-03A Drawbar Offset
60
WS82 Sticker: Mfg300 Warning
61
CM100-04 Drawtube
62
CM100-03A Bush Nylon
63
TRM120-16A Drawbar Assembly
64
CM100-01A Thrust Washer
65
C900 Coupling 50 MM H/D Winterhoff
66
FBH12065,FNN12 Bolt M12 X 65, Nyloc Nut
67
FBH12070,FNN12 Bolt M12 X 70, Nyloc Nut
68
TRM120-11 Drawbar Locking Pin
69
FBH16065,FWF16,FNN16 Bolt M16 X 65, Flat Washers, Nyloc Nut
70
LRM120-02A Engine Mounting Stool
71
TRM120-07L Transmission Guard L/H
71
TRM120-07R Transmission Guard R/H
72
WS118 Sticker: Grease Symbol
73
FSH08015,FWF08 S/Screw M8 X 15, Flat Washer
74
WS103 Sticker: Keep Wheel Nuts Tight
75
WS11 Sticker: Mow General Warning
76
FSH08010,FWS08,FWF08 S/Screw M8 X 10, Washer Spring, Washer Flat
77
LRM120-37 Plastic Plug-Kill Switch Mounting
78
LRM126-01A Kill Switch Assembly
79
S216
-013A Engine Mounting Plate
80
FSH10060,FWF10,FNN10
S/Screw M10 X 60, Flat Washers, Nyloc Nut
81
LRM123-03 Key Engine Pulley
