REPAIR PARTS KITS - MODEL T
SERVICE KITS
ITEM PART # DESCRIPTION
K1 71-B120 Brake kit - 115 Volt models
71-B240 Brake kit - 230-460 Volt models
71-B575 Brake kit - 575 Volt models
Complete with: Brake hub kit, brake
release lever, brake disk, spring cup,
studs, compression springs, brake
solenoid, solenoid cover, spacers,
mounting plate, pressure plate, feather
key and conduit.
K2 K75-10177 Brake hub kit
Complete with: Brake hub, set screw,
push on fastener and feather key.
K3 K72-12506 Clutch shaft kit (1/3 & 1/2 HP)
Complete with: Clutch plate, clutch
shaft, bearing 3/4" I.D., sprocket
41B10x3/4", 5L belt, motor pulley,
spring, clutch disc, shim washers,
castle nut, flatwashers, cotterpin, roll
pins and push on fastener.
K72-12507 Clutch shaft kit (3/4 & 1 HP)
Complete with: Same as kit above.
K4 K72-12508 Output shaft kit (1/3 & 1/2 HP)
Complete with: Output shaft, bearing,
roller chain with master link, limit
chain, shim washers, roll pins, push
ring 3/4" and sprockets (41B32 &
48B10).
K72-12509 Output shaft kit (3/4 & 1 HP)
Complete with: Same as kit above.
K5 K75-12870 Door arm kit
Complete with: Curved arm, straight
arm, door bracket and hardware.
NOT SHOWN
DOOR HEIGHT #48 CHAIN #41 CHAIN
(1/3 & 1/2 HP) (3/4 & 1 HP)
Doors 8' to 10' 19-5810 19-5112
Doors to 12' 19-5812 19-5112
Doors to 14' 19-5814 19-5114
Doors to 16' 19-5816 19-5116
Doors to 18' 19-5818 19-5118
Doors to 20' 19-5820 19-5120
Doors 20' to 24' 19-5824 19-5124
INDIVIDUAL PARTS
ITEM PART # DESCRIPTION
1 22-120 Brake solenoid, 115V
22-240 Brake solenoid, 230-460V
22-575-1 Brake solenoid, 575V
2 80-14414 Feather key
3 10-10166 Clutch plate
4 11-10014 Clutch shaft
5 12-10029 Bearing 3/4" I.D.
6 15-41B10G1 Sprocket, 48B10 x 3/4"
7 16-5L300 Cogged belt
8 17-10165 5L Motor pulley 7" O.D.
9 18-10164 Spring, clutch (1/3 & 1/2 HP)
18-10168 Spring, clutch (3/4 & 1 HP)
10 39-10167 Clutch disc
11 87-P-075 Push on fastener
12 12-10331 Bearing, flange
13 15-41B10G1 Sprocket, 41B10 x 3/4" (3/4 & 1 HP)
15-48B10GXX Sprocket, 48B10 x 3/4" (1/3 & 1/2 HP)
14 15-48B32GXX Sprocket, 48B32 x 3/4"
15 15-48B10G1 Sprocket, 48B10 x 3/4"
16 19-41047 Roller chain, #41 x 47 pitches
17 19-48033 Limit chain, #48 x 33 pitches
18 75-10170 Trolley
19 75-10174 Front Idler Assembly
20 K75-10259 Tracker Spacer
21 10-10205 Header Bracket
22 11-10130 Header Pivot Pin
23 K20-1033B-2LPMotor - models T3311L3, T3321L3
K20-3033B-4P Motor - models T3323L3, T3343L3
K20-3033M-5 Motor - model T3353L3
K20-1050B-2LPMotor - models T5011L3, T5021L3
K20-3050B-4P Motor - models T5023L3, T5043L3
K20-3050M-5 Motor - model T5053L3
K20-1075B-2LPMotor - models T7511L3, T7521L3
K20-3075B-4P Motor - models T7523L3, T7543L3
K20-3075M-5 Motor - model T7553L3
K20-1100B-2LPMotor - models T1011L3, T1021L3
K20-3100B-4P Motor - models T1023L3, T1043L3
K20-3100M-5 Motor - model T1053L3
NOT SHOWN
01-19458 Owner’s Manual - English
01-19458SP Owner’s Manual - Spanish
01-19458FR Owner’s Manual - French
DOOR DRIVE CHAIN KITS
