GB-54
Preparation Connections Initial Setup Using the Features DVR (Digital
Video Recorder)
Using the Features
via USB port
Using the DVD
Features
Hints and Tips, Specification
and Safety Warnings
Specification
Model L22DVDB10
Panel System 21.6 inch LCD panel
Display Resolution 1920 pixels (horizontal) x 1080 pixels (vertical)
Television System PAL I/BG/DK, SECAM L/BG/DK
Brightness 200-280 cd/m
2
Contrast Ratio 700-1000:1
Inputs/Output
SCART 1
HDMI 1
VGA 1
PC AUDIO 1
S-VIDEO 1
YPbPr 1
CI 1
USB 1
DVD 1
VIDEO IN (RCA) 1
AUDIO IN (RCA) 1 (L + R)
COAXIAL 1
RF (75 Ω) 1
Speaker Power 3 W + 3 W
Earphone (3.5mm) 1
Power Source 100V-240V~50/60Hz
Dimension( W x D x H) with base 526 x 200 x 372 mm
Weight (Net) 5.5 kg
Features and Specifications are subject to change without notice.
