Preparation
Front View and Controls
Item Description
1 POWER LED
Illuminates green when the TV is turned on. Illuminates red when the TV is in standby
mode. The LED will flash green and red when the timer programming has started in
the standby mode.
2 IR (Infrared Receiver)
Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
3 Disc Slot
Insert the disc with the label side towards you (12 cm discs only. Don't insert 8 cm
discs)
4 / Press to skip to the beginning of the previous / next chapter or track. (DVD mode)
5 Press to stop playback. (DVD mode)
6 Press to start playback or pause. (DVD mode)
7 Press to eject disc. (DVD mode)
8 INPUT
Press to select among different input signal sources:
DTV / ATV / SCART / YPbPr / PC / HDMI / AV / DVD / DMP.
Confirmed the selection on OSD menu.
9 MENU Displays the OSD (on screen display) menu.
10 CH + / – Press to select a channel or select a sub-menu from the OSD menu.
11 VOL + / –
Adjusts the volume.
Press to select and adjust a setting in the OSD menu.
12
Switches the TV on from standby mode.
Switches the TV back to standby mode.
13 USB
Allows the insertion of a USB storage device to play video, audio, photo and text files
(DMP mode) and record DTV programmes on to a USB storage device.
8
9
11
12
13
10
5
3
6
7
4
1 2
