Logik L26DIGB10 User Manual

GB-20
Preparation Connections Initial Setup Using the Features EPG (Electronic
Programme Guide)
Hints and Tips, Specification
and Safety Warnings
Using the DVD Features
CI (Common Interface) Information
The common interface allows the use of a Common Access Module to enable you to view scrambled (pay to view) services. These
services are provided by TopUp TV (UK only) and others. The Common Access Module and viewing card can be obtained from the
service provider.
Do not repeatedly insert or remove the
Common Access Module as this may damage
the interface and cause a malfunction.
This feature is not available in all countries.
To insert the Common Access Module
1. Before you insert the Common Access Module,
ensure that the TV is switched off and the viewing
card is inserted in accordance with the Service
Provider’s instructions.
2. Insert the Common Access Module into the slot.
Flip the Common Access Module to another side
and try again if you feel resistance.
3. Switch the TV on.
To remove the Common Access Module
1. Before you remove the Common Access Module,
ensure that the TV is switched off.
2. Pull the Common Access Module from the slot.
3. Switch the TV on.
To view the module information
1. Press the TV MENU button and then use the
buttons to select the CHANNEL menu.
2. Press the button and then the OK button or the
button to select CI Information.
VGA INPUT
Y Pb Pr
L R SPD IF
AUDIO
VGA INPUT
SCART
HDMI 1
HDMI 2
ANT
100 -240V ~ 50/60H z
AC- INPUT
COM MON I NTERF ACE
CAR D FAC E FRO NT
Rear View of TV
CI (Common Interface)
Allows the Common Access Module
to be inserted and access the content
that has been encrypted.
This screen is for illustration
purposes only.
3. A CI Information Main menu will pop up. Press the
buttons to display the Module Information,
Smart Card Information, Language, Software
Download. Press the OK button to confirm.
4. Press the TV MENU button to return back to the
previous menu.
5. Press the EXIT button to exit the menu.
VGA INPUT
Y Pb Pr
L R SPDIF
AUDIO
VGA INPUT
SCART
HDMI 1
HDMI 2
ANT
100-240V~ 50/60Hz
AC-INPUT
COMMON INTERFACE
CAR D FACE F R ONT
Common Access
Module
Auto tuning
DTV Manual tuning
ATV Manual tuning
Channel edit
CI information
CHANNEL
Module Information
Smart Card Information
Language
Software Download
Main menu
Press OK to select, or EXIT to quit
L26DIGB10_IB_final110210_running change6.indd 20 10/02/2011 3:12 PM

Logik L26DIGB10 Specifications

General

Brand	Logik
Model	L26DIGB10
Category	LCD TV
Language	English
