Logik L37S13 User Manual

12
R
AUX IN
COAXIAL
SUB-WOOFER
OUT
OPTICAL
L
R
AUX IN
COAXIAL
SUB-WOOFER
OUT
OPTICAL
L
LINE IN
Using the LINE IN Connection
Use a 3.5mm to 3.5mm stereo audio cable (not included) to connect the audio device’s
audio output socket to the unit’s LINE IN socket.
3.5mm to 3.5mm
stereo audio cable
(not included)
Coaxial Cable
Using the COAXIAL Connection
Use the coaxial cable to connect the audio device’s coaxial output socket to the unit’s
COAXIAL (input) socket.
Audio device
Audio device
Bottom view of the unit
Side view of the unit
L37S13_IB_RC_Final130628.indd 12 28/06/2013 3:13 PM

Logik L37S13 Specifications

General

Brand	Logik
Model	L37S13
Category	Speaker System
Language	English
