9
Remote Control Operation Range
• The remote control sensor at the front unit is
sensitive to the remote control’s commands up
to a maximum of 8 metres away and within a
maximum of a 30° arc.
• Please note that the operating distance may
vary depending on the brightness of the room.
Wall Mounting
Use an electronic stud nder to check the wall type before drilling and mounting.
SOURCE
MUTE
EQ
TREBLE
BASS
Vol
Vol
15° 15°
Max. 8 m
ø8mm
50mm
ø3mm
30mm
1. Drill 2 parallel holes (Ø 3-8 mm each according to wall type) in the wall. The distance
between the holes should be 401 mm.
401 mm
Wall (Front view)
Electronic stud nder
(not included)
Solid wall
Drywall, Plaster wall,
Lath wall, etc.
Drill
(not included)
L37S13_IB_RC_Final130628.indd 9 28/06/2013 3:13 PM
