9. Fix the plinth on the plinth tab. According
to your need to adjust the plinth height, the
adjustable range is from 56mm to 122mm.
56
122
plinth tab
plinth
10. To secure the dishwasher under the table top,
tighten the screws through the top sides of the
unit onto the table top.
11. Make sure your plumbing is suitable for use with
the dishwasher. If in doubt contact a qualified
plumber. This unit MUST BE connected to COLD
WATER MAINS using the new water inlet hose.
OLD HOSE SETS MUST NOT BE RE-USED. The
water pressure from the water mains needs to
be at a minimum of 0.04 MPa and a maximum of
1.00MPa.
• Connect one end of the safety water supply
hose to your dishwasher, and then connect
the other end of the hose to your water
mains. Please ensure the black rubber seal is
in place.
• After connecting the hose, turn on your water
mains and check for leaks.
• Connect the dishwasher to the mains socket.
Water mains
Y-Adaptor
(not included)
Connect
to another
appliance if
required.
Water supply hose
You may use a Y-Adaptor (not
included) for an additional water feed
for another appliance, for example
a washing machine. This is only
applicable for cold water mains. A
Y-Adaptor is available from most DIY
stores.
About the Safety Supply Hose
The safety supply hose consists of
the double walls. The hose’s system
guarantees its intervention by
blocking the flow of water in case of
the supply hose breaking and when
the air space between the supply
hose itself and the outer corrugated
hose is full of water.
