6
4. Take o the middle hinge by removing
the screws. Lift the lower door and place
it on a padded surface to prevent it from
scratching.
5. Remove the lower screws, bottom hinge
and levelling foot from the unit bottom.
Keep the hinge and foot together.
unscrew
6. Remove the other levelling foot from the
other side of the unit bottom and transfer
it to the corresponding position on the
opposite side of the unit bottom.
7. Unscrew and remove the bottom hinge
pin, turn the hinge over and screw back
the pin. Re-attach the bottom hinge,
screws and foot to the opposite side of
the unit.
unscrew unscrew
unscrew
screw
180˚
• Do not lay the unit at as this may damage the coolant system.
• During door reversal, when swapping the position of the bottom hinge or
adjusting the levelling feet, tilt the unit. Do not lay the unit at.
