23
10. Install the Aesthetic Panel onto the
dishwasher door. After the aesthetic panel
is installed, the tension of the dishwasher
door spring can be adjusted by rotating the
adjusting bolt. If the tension is right, the
door will remain horizontal in the fully open
position.
Hop hook
ST4*14 Countersunk
head screw
Lower hook
11. Remove the screws on both sides of the
dishwasher door and replace with ST3.5x45
screws. Ensure to tighten the screws and to
secure the Aesthetic Panel.
12. Adjust the bolt to loosen or tighten the
tension of the dishwasher door.
LID45W13N_IB_131028_Zell.indb 23 28/10/13 11:01 AM
