11
11. Make the middle hinge reverse the
direction 180°C, then transfer it to the left
property position. Make the middle hinge
pin in the upper hole of the lower door,
then tight the bolts.
12. Place the upper door back on. Ensure the
fridge door is aligned horizontally and
vertically so that the seals are closed on
all sides before finally tightening the top
hinge.
13. Insert the hinge bracket and screw it to
the top of the unit.
14. Use a spanner to tighten it if necessary.
Ensure the freezer door is aligned
horizontally and vertically, so that the
seals are closed on all sides before finally
tightening the hinge.
15. Put the hinge cover and the screw cover
back.
16. With the doors closed, check that the
doors are aligned horizontally and
vertically and that the seals are closed
on all sides before finally tightening the
bottom hinge. Re-adjust the levelling feet
as needed.
