4 ENGLISH
USB
Xbox One
USB
PC
INSTALLATION — XBOX ONE
— PC
Attach power adapter and USB cables as shown.
Every time your racing wheel connects with your system, it will
rotate fully to each side and then to the center to calibrate.
Yourwheel will be ready once this calibration is completed.
For PC to enable the force feedback and RPM LED features on
your G923 Wheel and Pedals you must install the Logitech G HUB
software. This can be found at logitechg.com/support/g923-xb1

Logitech G G923 Specifications

General

Type	Racing Wheel
Compatibility	PC, PlayStation 4, PlayStation 5
Rotation	900 degrees
Connection	USB
Force Feedback	TRUEFORCE
Pedals	Three (Throttle, Brake, Clutch)
Buttons	24-point selection dial
Shifter	Optional (sold separately)
Mounting	Built-in clamps
Power Supply	Power adapter
Weight	2.25 kg (wheel), 3.1 kg (pedals)
Dimensions	260 mm x 278 mm x 270 mm (wheel), 167 mm x 428.5 mm x 311 mm (pedals)
Material	Leather and metal
