Logitech G G923 User Manual

5 ENGLISH
MOUNTING CLAMPS
G923 Racing Wheel is equipped with a built in clamping system
for mounting to a table.
Push down and rotate clamp knobs to lock or unlock.
Rotate clamp knobs to tighten or loosen clamps.
Note:
Clamp extenders should be removed for attachment
tothickertables.

Logitech G G923 Specifications

General

Type	Racing Wheel
Compatibility	PC, PlayStation 4, PlayStation 5
Rotation	900 degrees
Connection	USB
Force Feedback	TRUEFORCE
Pedals	Three (Throttle, Brake, Clutch)
Buttons	24-point selection dial
Shifter	Optional (sold separately)
Mounting	Built-in clamps
Power Supply	Power adapter
Weight	2.25 kg (wheel), 3.1 kg (pedals)
Dimensions	260 mm x 278 mm x 270 mm (wheel), 167 mm x 428.5 mm x 311 mm (pedals)
Material	Leather and metal
