Logitech GROUP User Manual

English — 8
CONNECTING TO BLUETOOTH
®
DEVICE
To connect GROUP to your mobile device:
•
If your device is NFC enabled, touch the mobile device
to the NFC icon on the speakerphone, which should
enable Bluetooth acceptance on the mobile device OR
•
Hold down the Bluetooth button until the Activity
light on the speaker-phone starts blinking blue rapidly.
Follow the instructions on your mobile device to pair
with Bluetooth.
Note: When GROUP is paired and connected, the Bluetooth icon
on the speakerphone will appear bright. When paired but not
connected, it will be greyed out.
GROUP cannot pair to Bluetooth while streaming to USB.
If an attempt is made to pair to a mobile device while in a USB
call, an error beep will sound. Please wait until the USB call
is complete before pairing your mobile device.
USING LOGITECH GROUP
Video and audio
– Ensure GROUP is selected as the microphone, speaker and
camera in your video application.
– Simply start a call in your video application to use GROUP for
HD video and high quality audio. The Activity light will be blue
when video is streaming.
Audio only with Bluetooth
– Ensure GROUP is paired and connected to your mobile device
as outlined in Connection and Setup. Place a call on your
mobile device and enjoy the improved audio experience via
the GROUP speakerphone.

Logitech GROUP Specifications

General

Maximum frame rate	30 fps
Supported video modes	1080p
Video formats supported	H.264
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	1920x1080@30fps
Frequency range	120 - 14000 Hz
Echo cancellation	Yes
Built-in speaker(s)	No
Microphone pick-up range	6 m
Output voltage Total Harmonic Distortion (THD)	5 %
USB 2.0 ports quantity	1
Megapixel	- MP
Sensor type	-
Digital zoom	10 x
Focus adjustment	Auto
Image sensor size	- \
Number of camera presets	5
Field of view (FOV) angle	90 °
Power cable length	5 m
Pan range	0 - 260 °
Product type	Group video conferencing system
Product color	Black, Grey
Tilt angle range	0 - 130 °
Number of persons	- person(s)
Master (outer) case width	322 mm
Master (outer) case height	341 mm
Master (outer) case length	522 mm
Master (outer) case weight	9000 g
Harmonized System (HS) code	85176990
Battery capacity	210 mAh
Power source type	AC
Battery technology	Lithium
Cable lock slot type	Kensington
Minimum RAM	2048 MB
Minimum processor speed	2.4 GHz
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey
Other operating systems supported	ChromeOS
Windows operating systems supported	Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1
Microphone frequency	100 - 11000 Hz
Number of microphones	4
Microphone sensitivity	-28 dB
Microphone direction type	Omnidirectional
Sound pressure level (max)	91 dB
Microphone Total Harmonic Distortion (THD)	1 %

Weight and Dimensions

Depth	170 mm
Width	130 mm
Height	138 mm
Weight	585 g
Package depth	500 mm
Package width	145 mm
Package height	308 mm
Package weight	3977.5 g
