Logitech ZONE VIBE 100 User Manual

HEADPHONES LIGHT INDICATOR
Note:
- User-triggered behaviors, such as Bluetooth
®
pairing or link lost, will be prioritized then revert back to its previous status
once the behavior is completed.
Category Status Light
White
Power
Power ON Turn solid white and then dim
Battery charging Breathing
Battery fully charged Solid
Connectivity
Bluetooth
®
pairing Fast blinking
Bluetooth
®
connected Turn solid white and then dim
Link lost Dim white
Calls
Active call Solid
Incoming call Slow blinking
Red
Calls Mute Solid
Power Low battery (< 10%) Slow blinking
Factory reset
Fast blink from red to white for
three times then LED turn o
CHARGING
To conserve battery life, headphones
automatically power o after 30 minutes
without usage.
Sleep timer could be adjusted in Logi Tune.
The LED light on the headphones will blink slowly
in RED when the battery is low.
Charging via USB cable
1. Plug one end of the cable to the USB-C port
onthebottom of the earcup and the other end
into the USB-C charging port on your computer.
2. The LED light will start breathing white when
charging.
3. The LED light will turn solid white when
fullycharged.
– 2 hours will fully charge the battery.
– 5 minutes will give you 1 hour of playback.
4. The headphones can be used with Bluetooth
®
paired while charging.
8 English

Logitech ZONE VIBE 100 Specifications

Technical Specifications

microphone type	Dual omni-directional MEMS mics with directional beamforming and DSP
frequency response (speaker)	20-20kHz (music mode), 100-8kHz (talk mode)
frequency response (microphone)	100-8kHz
talk time	up to 18 hrs
listen time	up to 20 hrs
bluetooth version	5.2
wireless range	up to 30 m / 100 ft
cable length (USB-C charging cable)	4.9 ft (1.5 m)

Weight and Dimensions

headphones height	183.03 mm
headphones width	169.68 mm
headphones depth	73 mm
headphones weight	0.185 kg
earpad height	98.6 mm
earpad width	75.44 mm
earpad depth	19.3 mm
