8
6
9
Insert key (9) and turn clockwise to
switch on control current ready for
function activation.
The control functions of the pallet truck are located in the handle (6).
- The functions are dependent on the position of the handle!
Position A: Drive position
Drive current on
Brake deactivated
Position B: Stop/Brake/
Emergency Stop
Drive current off
Brake activated
3.0 How to operate the pallet truck
Note!!! Emergency stop
(8) must not be activated.
