Logosol B1001 G2 - Page 14

14
4
2
3
4
12 x – M12
12 x
12 x – M12x140
5
6
16 x – M12
16 x – M12x90
16 x – M12
3
2
1
4
8300-005-0040
78,5mm
8300-005-0050
If the machine is to be equipped
with hydraulics, these two cross
bunks should not be installed at
this point of assembly.
Now repeat steps 2–5 for the other rail.
