LogTag TRIX-8 V2 Work Instruction Manual Revision 10.17 Page 23/44
2.4 Press case halves together
Case halves are pressed together using pneumatic press.
2.5 Inspect Case Thickness
Inspection
Check thickness of case with gauge – Case thickness should be between 8.3 to 8.7 millimeters.
(Using thickness gauge slot as shown in Appendix 8)
