LogTag UTRIX-16 - Page 49

LogTag UTRIX Work Instruction Manual Revision 1.07 MP Release Page 49/52
APPENDIX 2: COMPONENT LIST
PCB revision 1.2 170515
P/N
Description
Q
Designator
1
100-15014-01-00
LF PCB MAIN L1 FR1 1.2 IG 51.05x47.86 UTRIX-16
1
R1.2 170515
2
211-00005-32-10
LF RES SMD 0 OHM 5% 1/8W 0805
5
R20, R23, R27, R28, R29
3
211-22705-41-10
LF RES SMD 270 OHM 5% 1/10W 0603
2
R3, R5
4
211-38205-41-10
LF RES SMD 8.2K 5% 1/10W 0603
1
R12
5
211-41005-41-10
LF RES SMD 10K 5% 1/10W 0603
2
R1, R10
6
211-41805-41-10
LF RES SMD 18K 5% 1/10W 0603
1
R21
7
211-43305-41-10
LF RES SMD 33K 5% 1/10W 0603
1
R25
8
211-44701-41-10
LF RES SMD 47K 1% 1/10W 0603
1
R11
9
211-51005-41-10
LF RES SMD 100K 5% 1/10W 0603
4
R13, R14, R19, R22
10
211-52205-41-10
LF RES SMD 220K 5% 1/10W 0603
5
R4, R8, R9, R16, R17
11
211-52208-32-12
LF RES SMD 220K +/-0.5% 0805 25PPM RT0805 YAGEO
1
R15
12
253-84714-04-32
LF CAP ELE 470uF 10% 4V ESS471M004F05 JING GUAN
1
C17
13
261-08271-44-11
LF CAP SMD 8.2pF +/-0.5 pF NPO 50V 0603
2
C2, C3
14
261-12251-44-11
LF CAP SMD 22pF +/-5% NPO 50V 0603
2
C5, C6
15
261-41014-44-11
LF CAP SMD 0.01uF +/-10% X7R 50V 0603
2
C16, C21
16
261-51014-44-11
LF CAP SMD 0.1uF 10% X7R 50V 0603
9
C1, C4, C7, C8, C9, C10, C11, C13, C14
17
261-61014-16-11
LF CAP SMD 1uF 10% X7R 16V 0603
3
C15, C20, C22
18
301-14011-01-00
LF XTAL LEAD 32.768KHz 20PPM 6PF CFS206 CITIZE
1
X1
19
301-14011-02-00
LF XTAL SMD 8.000MHz 30PPM 18PF HCM49 CITIZE
1
X2
20
311-12010-01-01
LF THR SMD SENSOR NTC 100K 0603 104KT1608T-1P
1
NTC1
21
331-07033-01-01
LF LED SMD RED 0805 GB-S M0805USW-TR CLEAR LUCKY
1
D1
22
331-07033-02-01
LF LED SMD YEL/GRN 0805 GB-SM0805UYGW-TR LUCKY
1
D2
23
351-01068-02-00
LF DIO SMD LBAS16LT1G SOT-23 LRC
1
D3
24
354-14011-01-00
LF DIO DUAL SMD PRTR5V0U 4D SOT-457 NXP
1
D4
25
361-03049-01-00
LF TSR NPN SMD BC847B SOT-23 PHILIPS
2
Q2, Q4
26
362-01068-01-00
LF TSR PNP SMD BC857B SOT-23 PHILIPS
1
Q1
27
364-14011-01-00
LF TSR MOSFET SMD BSS138 -7-F SOT-23 DIODES
1
Q3
28
381-11012-08-00
LF IC REGULATOR S-1206B3 3-M3T1G SOT-23-3 SEIKO
1
U5
29
381-15014-01-01
LF IC EEPROM W25Q16JVSNIG SOIC-8 WINBOND
1
U4
30
381-15014-03-00
IC FLASH AT25SF161B-SSHB-T, SOIC-8 ADESTO
0
U4
31
381-14011-02-01
LF IC MCU STM32L100RBT6 LQFP ST
1
U1
32
381-14011-03-01
LF IC AMP MCP6232-E/SN SOIC-8 MICROCHIP
1
U2
33
400-07033-03-00
LF SWH SMD TACT 12VDC 6x6x5 350G HUAN SHENG
2
SW1, SW2
34
761-07033-01-00
LF SPONGE BACK W/DOUBLE SIDE TAPE DIA15x2.5MM
1
35
503-41225-20-06
LF SCREW ST/B FLAT PHIL SST NAT M2X6
5
36
731-14011-01-00
FRONT LABEL USRIC, 2C PRINTING, 67.6x44MM, 0.25MM PC
1
37
843-15014-xx-xx
LBL PRT REAR UTRIX-16 (SPEC. REFER TO 843-14011-01-00)
1
38
843-15014-xx-xx
LBL PRT FRONT BARCODE (SPEC. REFER TO 843-14011-02-01)
1
39
650-01103-01-00
CHEM HUMISEAL CONFORMAL COATING 1B31
0.00009
40
650-01103-02-00
CHEM TINNER FOR HUMISEAL 1B31
0.00006
41
650-07033-01-00
CHM RTV COATING #3140 DOW CORNING 100ml/TUBE
0.00025
42
814-20711-09-01
LF BAG BB SSANGP 70x110 ANTI STATIC
1
