Instructions for use Lojer Modux nursing bed / Version 2.5
Copyright © Lojer Oy, 2022 60
Drawing
MODUXPUUT2 / New side rail
-
set 800 birch
Designer
MS / 2020
-
01
-
30
Item
Identifier
Description
Standard
Pcs
1 15008KOIVU 800 Birch end MODUX 2
2 TM40222 Upper slide for "AK-end" 4
3 71058 Rail of the head/foot end 800 & 900 MODUX 2
4 71057 Rail of the head/foot end 800 & 900 MODUX 2
5 R5011141T Rails' end plug 4
6 100000D20KR Side rails' locking tap 40223-1 2
7 100000D21KR Side rails' locking tap 40223-2 2
8 71056 AK-Side rail lower 2085 2
9 71055 AK-Side rail upper 2085 2
10 L9615RU Wire pull 96x15 black plastic 4
11 100000E11 Side rails' level rod Normal 2-part side rail 4
12 100000E12 MS Thread bushing D6x17-M5 inner thread 8
13 TM40224 Side rails' tap for AK-ends 8
14 TM40225 Lower slide for AK-ends 4
15 R238LS0510 Dowel pin D 5X10 A SFS 4906 8
16 R2520607035 Squeeze spring 0,6x7x35 - 10,5 4
17 R220510K Groove screw Countersunk head M5x10 Zn 965 16
18 R224PHS4035 Screw SPAX-S 4,0x35 Cheese head POZ ZN 8
19 R224LHS3520D SPAX-S 3.5X20 cheese head - countersunk ZNC 24
20 DIN 1481 DIN_1481-3x16 4
21 RH06060 Furniture screw M6x60 MESSINKI 4
22 R23803016A Spring pin D 3X16 V2A DIN 1481 2
23 PUUVÄLIKE Fastening piece for 800 & 900 ends 4
24 DIN 4762 Socket screw M8x70 8
25 R22616 NYLOC hex nut DIN 985-M6 2
