37
Install pushing plate of clutch
Install pushing rod and washer
Install washer of locking nut of driving gear
Install locking nut of driving gear
Caution: Concave side of washer face to clutch
and driving gear when installing washer of locking
nut of driving gear and clutch.
Install right crankcase cover
Install positioning pin and new gasket.
Install right crankcase cover
Install fastening screw, screw up bolt at hole
of positioning pin.
Torque of installation：（8～12）N·m
Install clutch cover
Install secondary filter and its cover
Install impeller of water pump
Install cover of water pump
