M10
Pipe settings
Enter the pipe outer diameter; the pipe outer
diameter must range from 10mm to
1200mm.
Note: Enter Either pipe outer diameter or
pipe outer perimeter
Enter the pipe wall thickness. Pipe wall
thickness is necessary.
Enter pipe material. The following options
are available:
0. PVC
1. CS Carbon Steel
2. SSP Stainless Steel Pipe
3. CIP Cast Iron Pipe
4. DIP Ductile Cast Iron Pipe
5. Copper
6. Alu. Aluminum pipe
7. ACP Asbestos Cement Pipe
8. FPG Fiberglass Pipe
9. Other It is possible to enter other
materials, which are not included in previous
eight items. Once item 9 is selected, the
relevant pipe sound velocity must be entered.
M11
Lining
Enter liner thickness.
Refer to item 9 "Other"; it is possible to enter
other materials, which are not included in
previous eight items. Once item 9 is selected,
the relevant pipe sound velocity must be
entered.
Use and to switch.
M11
