Transducer
Select transducer type
The following options are available:
0. Clamp-On C
1. Clamp-On D
2. Clamp-On X
3. Plus-In
4. Plus-In X
Select transducer Mounting Methods
Three mounting methods are available:
0. V Reflect method
1. Z Direct method
2. N
M14
Installation space
This value is calculated by the flow meter
The operator must mount the transducer
according to the transducer spacing displayed
(ensure that the transducer spacing is measured
precisely during installation). The system will
display the data automatically after the pipe
parameter had been entered.
M20
Damping
