16 USSC
KEY PART # DESCRIPTION QTY.
1.2 2469 Glass Support 2
2.2 17507 Combustion Chamber Glass 1
3.2 2483 Ceramic Fibre Glass Gasket (Long) 2
4.2 2482 Ceramic Fibre Glass Gasket (Short) 2
5.2 342/CC Combustion Chamber 1
6.2 2472 Ceramic Fibre Washer (D57 / D43) 6
7.2 16374 Air Intake Tube 3
8.2 15951 Spacing Bolt 2
9.2 2471 Ceramic Fibre Washer (D71 / D57) 4
10.2 2473 Burner Assembly Gasket 1
11.2 16360 Gas Intake Fitting 1
12.2 15756 Gas Intake Lock Fitting 2
13.2 2462 Gas Fitting Support 1
14.2 2465 Control Insulation 1
15.2 - Piezo Ignitor Nut 1
16.2 2463 Control Bracket 1
17.2 2464 Piezo Ignitor Bracket 1
18.2 12455 Piezo Ignitor 1
19.2 11699 Piezo Ignitor Button 1
20.2 11698 Knob Frame 1
21.2 16365 Control Rod 1
22.2 11626 Control Knob 1
23.2 2461 Cabinet Back 1
24.2 2419 Top Deflector 1
25.2 2421 Left Side Deflector 1
26.2 2420 Right Side Deflector 1
27.2 342/CA Air Chamber 1
28.2 2411 Cabinet Front 1
29.2 2413 Cabinet Glass Support 4
30.2 17767 Cabinet Glass 1
31.2 383 Grill, Cast Aluminum 1
32.2 17912 LONGVIE Logo 1
33.2 11634 Cabinet Slide 2
34.2 11315 Loop 1
FOR MODEL: DV12
DV12 - REPAIR PARTS LIST
