Lorex B451AJ-Z2 User Manual

Notes:
• Ensure that the arrow on the
mounting bracket is always pointing
up.
• The (optional) angled bracket must
be attached to the mounting bracket
before installation.
• Ensure the power cables from the
wall t comfortably through the hole
in the mounting bracket.
Figure 5-b

Lorex B451AJ-Z2 Specifications

General

Brand	Lorex
Model	B451AJ-Z2
Category	Intercom System
Language	English
