COMPACT, DISCRETE DESIGN, AUDIO RECORDING
DIGITAL VIDEO SURVEILLANCE RECORDER
Specifications:
Image size 12 Kbyte (Normal), 15 K byte (HIGH) 20K byte (Highest)
Video inputs 4 x 1Vp-p, 75 ohms, BNC
Audio inputs 1 x line-in, RCA
Audio output 1 x line-out, RCA
Supply voltage 12VDC , 4.A,(AC100V-240V 50/60Hz)
Power consumption Approx. 60 watts
Operating Temp. Range 10° ~ 40° C
Hard disk capacity 250GB HDD (Max 1000 G), 100% duty cycle,
Operating System Embedded RTOS
Backup USB Default (USB memory stick)
Back-up file formats VIDEO: VVF , picture: BMP
Compression Modified Motion Jpeg
Recording speed 60/50 (NTSC/PAL) ,
Record Scheduling Manual/ Motion Record/Time Record
Pre/Post alarm recording Alarm recording 5-30 Secs(motion)
Event/Log search Up to 127 for user login/out, configuration
changes, remote access, connects/disconnects
Playback Single, Quad
Activity detection Sensitivity levels: 4, motion detection
Dimension (unit): 8.6”(220mm) x 11.3”(288mm) x 1.8”(48mm) (W x D x H)
Weight (unit): 3.4lbs (1.5kg)
VGA Video OUT Video IN Audio IN/OUT DC-12V
©2009 Lorex Technology Inc.
As our product is subject to continuous improvement, Lorex
Technology & subsidiaries reserve the right to modify product
design, specifications & prices without notice and without
incurring any obligation. E&OE
3700 Koppers Street
Baltimore, Maryland 21227,
USA.
Lorex Technology Inc.
300 Alden Road, Markham,
Ontario L3R 4C1
Canada.
27012009
Dimensions:
Front
Side
1.8” (48mm)
8.6” (220mm)
11.3” (288mm)
Product Information:
Model#:
L114V251: with 250GB HDD
UPC Code: 7-78597-41625-1
Weight:
2.86kg/6.3 lbS
Cube:
0.01m / 0.39ft
Package
Dimensions:
400mm x 327mm x 85mm
15.7” x 12.9” x 3.35” (W x H x D)
Includes:
DVR, Remote Control, Power Supply, Software CD
Back Panel:
