11
Remove the reed from its location between the
lams by taking away the tie straps. You can cut
them but you can also lift the small ratchet
inside with the tip of a knife so they can be used
again.
Insert the locking pin into the hole in the top rail
and through the marked cord loops. Now the
shaft bars and lams are fixed in their neutral
position.
Turn the beater hinges into the bottom of the
uprights.
Connect the lower reed holder (the one with the
slanted side) to the uprights: Place the barrel
nut into the hole on the end of the lower reed
tray. Slide the upright with the notch over the
lower reed tray. Place the bolt with washer in
the hole and screw it into the barrel nut. Tighten
the bolt and, in the same way, assemble the
other upright on the other side of the reed
holder.
Screw the buffers into the holes at the sides of
the loom, see picture. If your loom has twelve
shafts you need to use the other hole you see
on the picture.
