Lowenstein Medical prismaAQUA User Manual

The right to make design modifications is reserved
11 Warranty
For information about warranty conditions, see the
Instructions for Use for your therapy device.
12 Declaration of conformity
For information about the declaration of conformity,
see the Instructions for Use for your therapy device.
Power capacity
Max. 30 VA (only in
combination with the
approved device)
Classification to EN 60601-1-11:
type of protection against electric
shock
degree of protection against electric
shock
protection against damaging ingress
of water and solids
Protection class II
Type BF
IP22
Classification to DIN EN 60601-1: op-
erating mode Continuous duty
Electromagnetic compatibility (EMC)
to DIN EN 60601-1-2
radio interference suppression
radio interference immunity
(Test parameters and limit values can
be obtained from the manufacturer on
request)
PEN 55011 B
IEC 61000-4 Parts 2
to 6, Part 11, Part 8
EN 61000-3 Parts 2
and 3
Heating of respiratory air Max. +3 °C
Humidification system output
to ISO 8185 at humidifier stage 7
without heatable tube at 23 °C
- 5 hPa (12.2 l/min)
- 10 hPa (18 l/min)
- 20 hPa (25.9 l/min)
22 mg/l
23 mg/l
20 mg/l
Humidification system output
to ISO 8185 at humidifier stage 7 with
heatable tube at 23 °C
- 5 hPa (12.2 l/min)
- 10 hPa (18 l/min)
- 20 hPa (25.9 l/min)
27 mg/l
28 mg/l
21 mg/l
Max. filling volume 400 ml
Pressure drop
Pressure drop does not
increase as a result of
combining therapy de-
vice WM 100 TD with
humidifier
WM 100 TH.
Maximum flow 248 l/min
Max. permissible operating pressure 50 hPa
Gas leak at max. operating pressure 0.0 l/min
WM 100 TH can be combined with
WM 090 TD
WM 100 TD
WM 110 TD
WM 120 TD
1 Operation/key
See the figures for how to fill, connect and remove
the humidifier:
Filling the humidifier
Filling the humidifier (alternative to )
Connecting the humidifier
Removing the humidifier
Dismantling the humidifier
Assembling the humidifier
Replacing the heater rod seal
Making humidifier settings on the therapy
device: operation differs depending on the therapy
device used. Follow the Instructions for Use for your
therapy device.
2 Introduction
2.1 Intended use
Humidifier WM 100 TH warms and humidifies respi-
ratory air and so prevents the mucous membranes in
the respiratory tract from drying out. It can be used in
clinical facilities and in the domestic sphere.
2.2 Description of function
The heatable humidifier operates in accordance with
the "pass-over" principle. The air supplied is passed
over the surface of warm water. This increases the rel-
ative humidity and the temperature of the air flow.
Heating capacity can be set on the therapy device in
stages.
2.3 Indications
Dry upper airways and respiratory air perceived to be
too cold. prismaAQUA may only be used in accor-
dance with a physician's recommendation.
2.4 Contraindications
The humidifier may not be used on patients whose
upper airways have been bypassed.
2.5 Side effects
No side effects are known.
3 Safety
Please read these Instructions for Use carefully. They
are a constituent part of the humidifier and must be
available at all times. In accordance with Directive 93/
42/EEC, observe the points below.
Risk of infection from germs in stale water!
Germs and bacteria can easily colonize and multiply
in stale water.
⇒ Clean the humidifier regularly.
⇒ Only use the humidifier with fresh water.
Risk of harm from operating the device outside
the specified ambient conditions
Using the device outside the specified ambient
conditions may lead to tolerances being exceeded
and to device failure and harm the patient.
⇒ Only operate the device within the specified am-
bient conditions (see "10 Technical data").
Material damage from overfilling!
Escaping water may run into the device and damage
it.
⇒ Take the humidifier off the device before filling it.
⇒ Only fill the humidifier up to the “max.” mark.
Material damage from hot water and aromatic
additives!
Hot water or aromatic additives (such as eucalyptus
oil) may damage the housing of the humidifier and
the heater rod.
⇒ Do not fill with hot water.
⇒ Do not use any aromatic additives.
3.1 General information
• In the domestic sphere, sterile or boiled water
need only be used in exceptional medical cases.
Do not use distilled water intended for technical
purposes as it may be microbiologically
contaminated.
• To prevent infection, bacterial contamination or
functional impairments, follow the instructions in
the section entitled “Hygiene treatment” (see "5
Hygiene treatment").
• If third-party items are used, functional failures
and restricted fitness for use may result.
Biocompatibility requirements may also not be
met. In such cases, please be aware that any
claim under warranty and liability will be void if
neither the accessories nor the genuine
replacement parts recommended in the
Instructions for Use are used.
WM 68250e 06/2017 EN
EN EN

Lowenstein Medical prismaAQUA Specifications

General

Brand	Lowenstein Medical
Model	prismaAQUA
Category	Humidifier
Language	English
