LS Control SpeedControl E 1045 - Page 10

Quick Guide function for SpeedControl E 1045
LS Control A/S
Industrivej 12
DK – 4160 Herlufmagle Page 10
1 phase motor with 50 hz and variable voltage – Figure 3
Control signal from 1 to 10V shown below.
1 phase motor with 40 - 50 hz and variable voltage – Figure 4
Control signal from 1 to 10V shown below.
0
50
100
150
200
250
10 15 20 25 30 35 40 45 50
Voltage [V]
Frequency [Hz]
1 phase w/50Hz and variable voltage
0
50
100
150
200
250
10 15 20 25 30 35 40 45 50
Voltage [V]
Frequency [Hz]
1 phase w/50Hz and variable voltage
1V
1
0
V
1V
5
V
1
0
V
