LS Control SpeedControl E 1045 - DIP-Switch and Jumper Settings for Motor

Quick Guide function for SpeedControl E 1045
LS Control A/S
Industrivej 12
DK – 4160 Herlufmagle Page 8
DIP-switch and jumper settings for motor
JUMPER
JP1: If JP1 is closed, the motor current is set for the smallest motor (e.g. 550W motors = 2,9A)
If JP1 is open, the motor current is set for the largest motor (e.g. 750W motors = 3,8A)
JP2: No function.
370W: JP1 closed – smallest motor – available soon
JP1 open – largest motor – available soon
550 - 750W: JP1 closed – smallest motor – 550W motors = 2,9A
JP1 open – largest motor – 750W motors = 3,8A
1,1 – 1,5kW: JP1 closed – smallest motor – 1,1kW motors = 4,9A
JP1 open – largest motor – 1,5kW motors = 7,0A
DIP-Switch
DIP1 = OFF and DIP2 = OFF ------- ramp up time = 5sec. and ramp down time = 15 sec.
DIP1 = ON and DIP2 = OFF ------- ramp up time = 15sec. and ramp down time = 30 sec.
DIP1 = OFF and DIP2 = ON ------- ramp up time = 15sec. and ramp down time = 60 sec.
DIP1 = ON and DIP2 = ON ------- ramp up time = 15sec. and ramp down time = 120 sec.
DIP3 = OFF and DIP4 = OFF ------- 3 phase motor with parable shaped Hz/voltage curve. See fig. 1.
DIP3 = ON and DIP4 = OFF ------- 3 phase motor with linear shaped Hz/voltage curve. See fig. 2.
DIP3 = OFF and DIP4 = ON ------- 1 phase motor with 50Hz fixed and variable voltage. See fig. 3.
DIP3 = ON and DIP4 = ON ------- 1 phase motor with 40 - 50Hz and variable voltage. See fig. 4.
Basic settings
Minimum frequency = 10Hz
Maximum frequency = 50Hz
Minimum Voltage on control signal = 1V
Maximums Voltage on control signal = 10V
1
2
3
4
ON
OFF
DIP
-
Switch
JP
1
JP2
Jumper
