Quick Guide function for SpeedControl E 1045
LS Control A/S
Industrivej 12
DK – 4160 Herlufmagle Page 3
Product description
SpeedControl E 1045 is a frequency converter for control of standard asynchronous motors with 3 phase
or single phase supply. SpeedControl E 1045 is supplied in an IP54 sturdy metal housing for demanding
environments. The compact construction offers many mounting options. The construction is not equipped
with active cooling, the sound level is very low and the frequency converter is maintenance free. Descrete
ligt grey colour for reduction of heat absorption.
For information on Modbus control of the frequency converter, see LS Controls home page.
http://www.lscontrol.com
Technical specifications
E1045
-
37
0
W
E1045
-
75
0
W
E1045
-
150
0
W
Supply voltage
Uin = 230VAC ±10% - 50Hz Uin = 230VAC ±10% - 50Hz Uin = 230VAC ±10% - 50Hz
Supply current
Max. Iin = 4A Max. Iin = 6.3A Max. Iin = 10A
Supply power
Max. 370W Max. 750W Max. 1500W
Motor voltage
3 x AC - 0 – Uin 3 x AC - 0 – Uin 3 x AC - 0 – Uin
Motor
current
Max. 2,4A* Max. 4,0A* Max. 7,0A*
Motor frequency
0 – 100Hz 0 – 100Hz 0 – 100Hz
16Vdc output
100mA 100mA 100mA
10Vdc output
30mA 30mA 30mA
0
–
10V input
0 – 10V, Ri = 7 kOhm. 0 – 10V, Ri = 7 kOhm. 0 – 10V, Ri = 7 kOhm.
Alarm Relay
Max. 30Vdc/3A & 230VAC/3A Max. 30Vdc/3A & 230VAC/3A Max. 30Vdc/3A & 230VAC/3A
Temperatur
e
0 – 40°C 0 – 40°C 0 – 40°C
Modbus A
Net plus Net plus Net plus
Modbus B
Net minus Net minus Net minus
Modbus C
Net GND Net GND Net GND
* The motor current measuring is optimized for most precise reading around maximum motor current.
EMC
Frekvensomformeren (IP54) overholder standarden for elektriske motordrev med variabel hastighed.
Frekvensomformeren er klassificeret som et Power Drive System (PDS) af ”category C2” (EN 61800 – 3).
· EN 61800 – 3:2005 – Elektriske motordrev med variabel Hastighed – Del 3: EMC – produktstandard
med specifikke prøvningsmetoder.
· EN 61800 – 3/A1:2012 – Elektriske motordrev med variabel Hastighed – Del 3: EMC –
produktstandard med specifikke prøvningsmetoder.
· EN 61800 – 5 – 1:2007 – Elektriske motordrev med variabel Hastighed – Del 5 – 1: Sikkerhedskrav –
Elektrisk, termiske og energimæssige.
Ved køb af frekvensomformer i IP00, kan LS Control ikke garantere ovenstående standarder.
