1.
Introduction
Ethernet communication option module connects the iS7 inverter to the
Ethernet network. It supports 2 kinds of protocol, Modbus/TCP and
Ethernet/IP.
Controlling and monitoring of inverter can be done by PLC sequence program
or any Master Module. Since Ethernet which constitutes Internet has been
used and IPv4 has been supported, wherever Internet can be done, controlling
and monitoring is possible. But, Ethernet network of the factory has to be
connected to Internet through Gateway.
With simple wiring, installation time can be reduced and maintenance
becomes easier.
2.
Ethernet Technical Features
3.
Product Constituents
This product is consisting of the Ethernet communication module, a screw and
User Manual.
Transmission Speed
10Mbps, 100Mbps
Transmission Method
Baseband (Half, Full Duplex)
Max. Extended Distance between
Nodes
100m (Node - Hub)
Max. Node Number
Hub connection
Auto Negotiation
Supported
Max. Frame size
1500 Bytes
Communication Zone Access Method
CSMA/CD
Frame Error Checking Method
CRC32
Recommended Connecting Socket
3 Socket
Recommended Cable
UTP, FTP, STP
(Refer to page 6 for details.)
