②
②②
② Telescopic type
Pull up the link pin (1) and adjust the stabilizer by
moving the pin in stabilizer holes.
After the adjustment, insert the pin into the desired
hole and let it tightened firmly by locking spring.
▶
When adjusting the stabilizer’s
length, adjust the implement’s
swinging clearance to be
20~40mm (0.79~1.57 in.) left and
right.
Notice
①
①①
①
(5) Reference of Implement installation part
19
(0.74)
A
B
C
(Max)
G H J L N
CAT.1
19.3
(0.75)
683
(26.8)
12
(0.47)
39
(1.53)
35
(1.53)
22.4
(0.88)
22
(0.86)
44.5
(1.75)
69
(2.71)
76
(2.99)
44
(1.73)
D
(Min)
K
E
(Max)
F
(Min)
4
4 4
4 - 14
Unit : mm
(unit : inch)
