BUCKET, DIPPERSTICK ASSEMBLY
REF.
NO
LS PART NO PART NO DESCRIPTION QTY I.C REMARK
40231071 BT664-23100-01 BUCKET ASS'Y, 9 1
40231072
BT664-23200-01 BUCKET ASS'Y, 12 1
40231074
BT664-23400-02 BUCKET ASS'Y, 18 1
40231075
BT664-23500-02 BUCKET ASS'Y, 24 1
40231076
BT664-23600-02 BUCKET ASS'Y, 36 1
2 40231056 BT200-22100 DIPPERSTICK ASS'Y 1
3 40231079 BT664-25100 LINK ASS'Y 1
4 40231078
BT664-24200-02 LINK-RH 1
5 40231077
BT664-24100-02 LINK-LH 1
6 40231094
BT664-71600-01 PIN, ∅30-195.5L 2
8 40231092
BT664-71400-02 PIN, ∅30-154.5L 2
9 40230880
10121-M0803-60
HEX.BOLT, M8-1.25P 60L 4
10 40230896 1021N-M0803 NUT-SELFLOCK, M8-1.25P 4
11 40228707 802G0-T1900 NIPPLE,GREASE, 1/8" 4
13 40231037 BH11-0116 SOCKET BRACKET 1
14 40231036 BH11-0115 SOCKET 1
15 40228698 50120-M540K CABLE TIE, 540mm BLACK 2
16 40228607
10121-M0803-50
HEX.BOLT, M8-1.25P 50L 2
17 40228629 10211-M0803 HEX.NUT, M8-1.25P 2
18 40230979 83040-4440D BUSHING, 404440 2
19 40230978 83030-3440D BUSHING, 303440 2
20 40230907 2010-3025 BUSHING, 252830 4
21 40231097 BT664-72000 PIN, ∅25-195.5L 2
22 40230884
10121-M1004-60
HEX.BOLT, M10-1.5P 60L 2
23 40228634 1021N-M1004 NUT-SELFLOCK, M10-1.5P 2
