6 -3
XG3025 XG3025H
REAR PTO
Type Independent rear PTO / MID PTO(optional)
No. of speed 1 speed gear
PTO / Engine 540 rpm / 2509 rpm
HYDRAULIC LIFT
3 Point linkage CAT1
Draft load detection N/A
Lowering speed
control and cylinder
fixing device
Down speed control valve
Pump Gear pump type, Engine drive
Rated flow 30.0LPM (7.9GPM)
System pressure 16.7MPa (2418psi)
Lift
capacity
Lower link
end
820 kgf (1808 lbf)
24” behind
lift point
650 kgf (1433 lbf)
REMOTE
CONTROL
No. of spool Double acting , Spring return type (optional)
No. of Q/coupler N/A / 2EA / 4EA (optional)
F/Loader coupler Front outlet valve
STEERING SYSTEM
Type Hydrostatic
Oil Transmission oil
Min. turning radius
(without brake)
3.2m (10.5 ft)
Min. turning radius
(with brake)
2.8m (9.2 ft)
Max. steering angle
48°
No. of steering turns 3.7 (right) / 2.9 (left) turns (lock to lock)
Rated flow
17.5 LPM
(4.6 GPM)
17.5 LPM
(4.6 GPM)
System pressure 11.8MPa (1707 psi) 11.8MPa (1707 psi)
