3 -8
PTO switch
(7) PTO switch (Independent PTO)
z The engine starts only when PTO switch is
placed in OFF position for safety.
z After starting engine, you must comply with the
following instruction about the PTO operation.
1. Check the safety around the implement.
2. Place the PTO gear lever (if fitted) to suitable
position for your work condition.
3. Place the PTO switch to ON position. The
PTO shaft shall rotate.
4. When the PTO is rotating, PTO operation
indicator on the instrument panel shall be ON.
5. If you want to stop the PTO temporarily while
operating, push the PTO switch to OFF position.
▶ Before attaching or checking the PTO driven equipment,
- Always place the PTO switch in OFF position, and PTO gear lever(if fitted) in
NEUTRAL position.
▶ Even If releasing clutch pedal or lifting 3-point linkage to maximum position, PTO
shall not be stopped. Pay attention to the surroundings to prevent a accident.
▶ Do not engage the PTO at high engine speed. Sudden engagement can cause
damage to some implements and PTO clutch. Engage PTO at low RPM, and then
raise the engine speed up.
Warning
ON : PUSH AND TURN
OFF : PUSH
