IMBH10. SUBFRAME
NO. PART NO. DESCRIPTION Q'TY I.C. SERIAL OR DATE
0 40231126 SUBFRAME ASS'Y 1
40320334 SUBFRAME ASS'Y 1 2014.12.15~
1 40231127 CROSS BAR W.A. 1
40320335 CROSS BAR W.A. 1 2014.12.15~
2 40231128 RAIL W.A. 1
40256024 RAIL W.A. 1 2011.02.22~
40286940 RAIL W.A 1 2014.12.15~
3 40231129 BRACKET_MID W.A. 1
40256022 BRACKET_MID W.A. 1 2011.02.22~
4 40231116 BRACE 2
5 40230905 PIN 2
6 40228656 RING-PIN,∅10 2
7 40228623 HEX.BOLT-HT,M14-2.0P 60L 4
8 40230601 HEX.BOLT-HT,M14-2.0P 40L 4
40264168 HEX.BOLT-HT,M14-2.0P 50L 4 2019.08.08~
9 40230894 HEX.BOLT-HT,M20-2.5P 70L 4
10 40230895 HEX.BOLT-HT,M22-2.5P 70L 4
11 40230893 HEX.BOLT-HT,M14-2.0P 55L 2 2011.02.22~
12 40264330 SPACER 1 ~2012.05.08
14 40228643 WASHER-SPRING,M14 8
40228643 WASHER-SPRING,M14 10 2011.02.22~
15 40228645 WASHER-SPRING,M20 4
16 40230899 WASHER-SPRING,M22 4
21 40228637 HEX.NUT-HT,M14-2.0P 4
22 40228639 HEX.NUT-HT,M20-2.5P 4
23 40230898 HEX.NUT-HT,M22-2.5P 4
- 47 -
