IMBH10. SUBFRAME
NO. PART NO. DESCRIPTION Q'TY I.C. SERIAL OR DATE
0 40231130 SUBFRAME ASS'Y 1
1 40231131 CROSS BAR W.A. 1
2 40231132 RAIL W.A. 1
3 40231133 BRACKET_MID W.A. 1
4 40231116 BRACE 2
5 40230905 PIN 2
6 40230904 RING PIN 2
8 40228623 HEX.BOLT-HT,M14-2.0P 60L 4
9 40230894 HEX.BOLT-HT,M20-2.5P 70L 4
10 40230895 HEX.BOLT-HT,M22-2.5P 70L 4
11 40230601 HEX.BOLT-HT,M14-2.0P 40L 2 2011.03.21~
14 40228643 WASHER-SPRING,M14 4
40228643 WASHER-SPRING,M14 6 2011.03.21~
15 40228645 WASHER-SPRING,M20 4
16 40230899 WASHER-SPRING,M22 4
21 40228637 HEX.NUT-HT,M14-2.0P 4
22 40228639 HEX.NUT-HT,M20-2.5P 4
23 40230898 HEX.NUT-HT,M22-2.5P 4
- 51 -
