IMBH10. SUBFRAME
NO. PART NO. DESCRIPTION Q'TY I.C. SERIAL OR DATE
0 40324623 SUBFRAME ASS'Y 1
40342994 SUBFRAME ASS'Y 1 2016.03.15~
1 40324624 CROSS BAR W.A. 1
2 40286940 RAIL W.A 1
3 40256022 BRACKET_MID W.A. 1
4 40286935 BRACE 2
40342997 BRACE 2 2016.03.15~
5 40230905 PIN 2
6 40228656 RING-PIN,10 2
7 40228623 HEX.BOLT-HT,M14-2.0P 60L 4
8 40230601 HEX.BOLT-HT,M14-2.0P 40L 4
40264168 HEX.BOLT-HT,M14-2.0P 50L 4 2016.03.15~
9 40230894 HEX.BOLT-HT,M20-2.5P 70L 4
40343000 HEX.BOLT-HT,M20-2.5P 80L 4 2016.03.15~
10 40230895 HEX.BOLT-HT,M22-2.5P 70L 4
40343501 HEX.BOLT-HT,M22-2.5P 80L 4 2016.03.15~
11 40228643 WASHER-SPRING,M14 10
12 40228645 WASHER-SPRING,M20 4
13 40230899 WASHER-SPRING,M22 4
14 40228637 HEX.NUT-HT,M14-2.0P 4
15 40228639 HEX.NUT-HT,M20-2.5P 4
16 40230898 HEX.NUT-HT,M22-2.5P 4
17 40230893 HEX.BOLT-HT,M14-2.0P 55L 2
18 40343504 HEX.BOLT-HT,M20-2.5P 90L 2 2016.03.15~
19 40343502 NUT-SELFLOCK,M20-2.5P 4 2016.03.15~
20 40343503 NUT-SELFLOCK,M22-2.5P 4 2016.03.15~
- 53 -
