IMBH10. SUBFRAME
NO. PART NO. DESCRIPTION Q'TY I.C. SERIAL OR DATE
1 40381344 CROSS BAR W.A. 1
2 40389993 RAIL W.A 1
3 40256022 BRACKET_MID W.A. 1
4 40342997 BRACE 2
5 40230905 PIN 2
6 40228656 RING-PIN,∅10 2
7 40230601 HEX.BOLT-HT,M14-2.0P 40L 4
40264168 HEX.BOLT-HT,M14-2.0P 50L 4 2019.08.08~
8 40230893 HEX.BOLT-HT,M14-2.0P 55L 2
9 40343000 HEX.BOLT-HT,M20-2.5P 80L 2
10 40343504 HEX.BOLT-HT,M20-2.5P 90L 2
11 40343501 HEX.BOLT-HT,M22-2.5P 80L 4
12 40228643 WASHER-SPRING,M14 6
13 40228645 WASHER-SPRING,M20 4
14 40230899 WASHER-SPRING,M22 4
15 40228639 HEX.NUT-HT,M20-2.5P 4
16 40230898 HEX.NUT-HT,M22-2.5P 4
17 40343502 NUT-SELFLOCK,M20-2.5P 4
18 40343503 NUT-SELFLOCK,M22-2.5P 4
- 55 -
