LS tractor XR3037H User Manual

IMBH10. SUBFRAME
NO. PART NO. DESCRIPTION Q'TY I.C. SERIAL OR DATE
1 40324626 CROSS BAR W.A. 1
2 40286941 RAIL W.A. 1
3 40231133 BRACKET_MID W.A. 1
4 40231116 BRACE 2
40342998 BRACE 2 2016.03.15~
5 40230905 PIN 2
6 40230904 RING PIN 2
8 40228623 HEX.BOLT-HT,M14-2.0P 60L 4
9 40230894 HEX.BOLT-HT,M20-2.5P 70L 4
40343000 HEX.BOLT-HT,M20-2.5P 80L 2 2016.03.15~
10 40230895 HEX.BOLT-HT,M22-2.5P 70L 4
40343501 HEX.BOLT-HT,M22-2.5P 80L 4 2016.03.15~
11 40230601 HEX.BOLT-HT,M14-2.0P 40L 2
12 40343504 HEX.BOLT-HT,M20-2.5P 90L 2 2016.03.15~
14 40228643 WASHER-SPRING,M14 6
15 40228645 WASHER-SPRING,M20 4
16 40230899 WASHER-SPRING,M22 4
21 40228637 HEX.NUT-HT,M14-2.0P 4
22 40228639 HEX.NUT-HT,M20-2.5P 4
23 40230898 HEX.NUT-HT,M22-2.5P 4
24 40343502 NUT-SELFLOCK,M20-2.5P 4 2016.03.15~
25 40343503 NUT-SELFLOCK,M22-2.5P 4 2016.03.15~
