IMBH10. SUBFRAME
NO. PART NO. DESCRIPTION Q'TY I.C. SERIAL OR DATE
1 40391462 CROSS BAR W.A. 1
2 40391463 RAIL W.A. 1
40394389 RAIL W.A. 1 2018.08.18~
3 40386631 BRACKET_MID W.A. 1
4 40342998 BRACE 2
5 40230905 PIN 2
6 40228656 RING PIN 2
7 40230601 HEX.BOLT-HT,M14-2.0P 40L 2
8 40343000 HEX.BOLT-HT,M20-2.5P 80L 2
9 40343504 HEX.BOLT-HT,M20-2.5P 90L 2
10 40343501 HEX.BOLT-HT,M22-2.5P 80L 4
11 40228643 WASHER-SPRING,M14 2
12 40228645 WASHER-SPRING,M20 4
13 40230899 WASHER-SPRING,M22 4
14 40228639 HEX.NUT-HT,M20-2.5P 4
15 40230898 HEX.NUT-HT,M22-2.5P 4
16 40343502 NUT-SELFLOCK,M20-2.5P 4
17 40343503 NUT-SELFLOCK,M22-2.5P 4
- 61 -
