IMBH20. MAIN FRAME
NO. PART NO. DESCRIPTION Q'TY I.C. SERIAL OR DATE
1 40231069 MAIN FRAME ASS'Y 1
40372133 MAIN FRAME ASS'Y 1 2017.07.13~
2 40231065 CROSS BAR 1
3 40231088 STABILIZER ASS'Y-RH 1
4 40231086 STABILIZER ASS'Y-LH 1
5 40231087 FOOT PLATE 2
6 40231064 BRACKET-CUSHION 2
7 40230876 CUSHION 2
8 40261802 BUSHING 2
9 40231089 PIN,∅25-171L 4
10 40231090 PIN,∅25-139L 2
11 40231091 PIN,∅25-175L 2
12 40231104 STABILIZER LOCK 2
13 40231105 WASHER 2
14 40261484 HEX.BOLT,M10-1.5P 90L 2
15 40228641 WASHER-SPRING,M10 2
16 40230877 RUBBER STOP 2
17 40231035 U-BOLT,∅40,5/16-18 1
18 40261479 HEX.BOLT,M8-1.25P 50L 8
19 40230896 NUT-SELFLOCK,M8-1.25P 8
20 40228634 NUT-SELFLOCK,M10-1.5P 4
21 40230901 HEX.NUT,5/16 4
22 40230888 HEX.BOLT,M16-2.0P 60L 4
23 40228644 WASHER-SPRING,M16 4
24 40228636 NUT-SELFLOCK,M16-2.0P 4
25 40261482 HEX.BOLT,M10-1.5P 50L 2
26 40228647 WASHER-PLAIN,M10 4
27 40231034 SPRING 2
28 40230956 NIIPPLE GREASE, PT1/8 4
29 40230957 NIIPPLE GREASE, PT1/8 45˚ 2
- 63 -
