IMBH21. SEAT, CONTROL(WALVOIL)
NO. PART NO. DESCRIPTION Q'TY I.C. SERIAL OR DATE
1 40294001 VALVE ROOM W.A. 1
40343508 VALVE ROOM W.A. 1 2016.03.15~
2 40294002 COVER, FRONT 1
3 40294003 TOP COVER 1
4 40231062 FOOT PLATE - CENTER 1
5 40231061 FOOT PLATE - RH 1
6 40231060 FOOT PLATE - LH 1
7 40294004 GUIDE BAR 1
8 40231053 SWING PIN HANGER 1
9 40231054 M/C BOSS 1
10 40230892 HEX.BOLT-HT,M12-1.75P 30L 6
11 40228642 WASHER-SPRING,M12 6
12 40228631 HEX.NUT,M12-1.75P 6
13 40230889 BOLT-SEM'S,M8-1.25P 25L 15
14 40228629 HEX.NUT,M8-1.25P 12
15 40230890 BOLT-SEM'S,M8-1.25P 40L 4
16 40294005 BOOT LEVER ASS'Y 2
40343509 BOOT LEVER ASS'Y 2 2016.03.15~
40369943 BOOT LEVER ASS'Y 2 2017.05.11~
17 40294006 HAND LEVER 2
40343510 HAND LEVER 2 2016.03.15~
18 40231103 SWING PIN 1
19 40230882 HEX.BOLT,M10-1.5P 40L 1
40432634 HEX.BOLT,M10-1.5P 20L 1 2020.03.24~
20 40231081 SUPPORT SEAT 1
21 40256413 PLATE, SEAT 1
22 40231138 SEAT 1
40373768 SEAT 1 2017.08.05~
23 40446578 LINK ASS'Y 1
24 40231084 PIN, ∅12 1
25 40255401 HEX.BOLT,M12-1.75P 100L 1
26 40230887 HEX.BOLT,M12-1.75P 110L 1
27 40228642 WASHER-SPRING,M12 6
28 40228635 NUT-SELFLOCK,M12-1.75P 2
29 40228615 HEX.BOLT-HT,M12-1.75P 35L 4
30 40230900 HEX.BOLT-HT,5/16-18 3/4" 4
40245406 BOLT-SEM'S,M8-1.25P 20L 4 2017.08.05~
31 40228655 R-PIN,∅31
- 65 -
