LS tractor XR3037H User Manual

IMBH30. SWING FRAME
NO. PART NO. DESCRIPTION Q'TY I.C. SERIAL OR DATE
1 40231080 SWING FRAME ASS'Y 1
2 40231106 SWING CYL.PIN,∅25-118L 2
3 40231098 PIN,∅40-117L 2
4 40261809 LOCK 1
40343506 LOCK 1 2016.03.15~
5 40231101 PIN, ∅22-190L 1
6 40231100 HANDLE SET 1
40343507 HANDLE SET 1 2016.03.15~
7 40231031 PLASTIC BALL 1
8 40231102 LOCK 1
9 40230946 SNAP RING, C22 2
10 40231055 SPRING 1
11 40261806 PIN 1
12 40228634 NUT-SELFLOCK,M10-1.5P 1
13 40230896 NUT-SELFLOCK,M8-1.25P 6
14 40256377 HEX.BOLT,M8-1.25P 60L 3
15 40294062 HEX.BOLT,M8-1.25P 50L 2
16 40230878 HEX.BOLT,M8-1.25P 25L 1
17 40230879 HEX.BOLT,M8-1.25P 35L 1
18 40229894 HEX.BOLT,M10-1.5P 35L 1
19 40228630 HEX.NUT,M10-1.5P 1
- 67 -
