IMBH50. BUCKET, DIPPERSTICK
NO. PART NO. DESCRIPTION Q'TY I.C. SERIAL OR DATE
40231071 BUCKET ASS'Y(9) 1
40394246 BUCKET W.A(9) 1 2018.09.05~
40231072 BUCKET ASS'Y(12) 1
40394247 BUCKET W.A(12) 1 2018.09.05~
40231073 BUCKET ASS'Y(16) 1
40394248 BUCKET W.A(16) 1 2018.09.05~
40231074 BUCKET ASS'Y(18) 1
40394249 BUCKET W.A(18) 1 2018.09.05~
40231075 BUCKET ASS'Y(24) 1
40394250 BUCKET W.A(24) 1 2018.09.05~
40231076 BUCKET ASS'Y(36) 1
40394251 BUCKET W.A(36) 1 2018.09.05~
2 40231058 DIPPERSTICK ASS'Y 1
3 40231079 LINK ASS'Y 1
40400865 LINK ASS'Y 1 2018.11.01~
4 40231078 LINK-RH 1
40400867 LINK-RH 1 2018.11.01~
5 40231077 LINK-LH 1
40400866 LINK-LH 1 2018.11.01~
6 40231094 PIN,∅30-195.5L 2
8 40231092 PIN,∅30-154.5L 2
9 40256377 HEX.BOLT,M8-1.25P 60L 4
10 40230896 NUT-SELFLOCK,M8-1.25P 4
11 40228707 NIPPLE,GREASE,1/8" 4
13 40231037 SOCKET BRACKET 1
14 40231036 SOCKET 1
15 40228698 CABLE TIE,540mm BLACK 2
16 40256356 HEX.BOLT, M8-1.25P 20L 2
17 40228629 HEX.NUT,M8-1.25P 2
18 40230979 BUSHING,404440 2
19 40230978 BUSHING,303440 2
20 40230907 BUSHING,252830 4
21 40231097 PIN,∅25-195.5L 2
22 40230884 HEX.BOLT,M10-1.5P 60L 2
23 40228634 NUT-SELFLOCK,M10-1.5P 2
1
- 71 -
