IMBH61. HYDRAULIC LINE
NO. PART NO. DESCRIPTION Q'TY I.C. SERIAL OR DATE
1 40230959 NIPPLE,PT3/8×3/4-16NUF,SWIVEL 90° 1
2 40228721 QUICK COUPLER,PT3/8" FEMALE 2
3 40230676 DUST-CAP,3/8" WHITE MALE 2
4 40228729 DUST-CAP,3/8" WHITE FEMALE 2
5 40228720 QUICK COUPLER,PT3/8" MALE 2
6 40230961 NIPPLE,PF1/2,O-RING×PT3/8 1
7 40228757 O-RING,1BP18 1
8 40230975 HOSE ASS'Y,4(3/4-16UNF)-1(PT1/2) 1700L(3/8) 2
9 40230968 QUICK COUPLER,PT1/2 FEMALE 2
10 40230970 DUST-PLUG,1/2" WHITE MALE 1
11 40228715 NIPPLE,PT3/8×3/4-16UNF,HOSE 90˚ 3
12 40230969 DUST-PLUG,1/2" BLACK MALE 1
13 40228698 CABLE TIE,540mm BLACK 5
- 40228758 TEFRON TAPE 1
- 77 -
