IMBH61. HYDRAULIC LINE
NO. PART NO. DESCRIPTION Q'TY I.C. SERIAL OR DATE
1 40400878 DIVERTER VALVE, DF3 VIE1/2 CC-OPEN 1
2 40228653 BONDED SEAL, 1/2" 5
3 40326740 NIPPLE, PF1/2,COPPER x 3/4-16UNF,HOSE 3
4 40228710 NIPPLE, 3/4-16UNF,HOSE x 3/4-16UNF,HOSE,SWIVEL 90° 2
5 40400882 NIPPLE, PT1/2 x 3/4-16UNF,HOSE, SWIVEL 90° 1
6 40230968 QUICK COUPLER, PT1/2 FEMALE 2
7 40401016 DUST PLUG, 1/2 MALE RED 1
8 40404034 VALVE BRACKET 1
9 40230890 SEM'S BOLT, M8-1.25P 40L 2
10 40228629 NUT, M8-1.25P 2
11 40400884 BENZO BOLT, PF1/2 1
12 40400880 HOSE, 4(3/4-16UNF) x BENZO(PF1/2) 2280L(3/8) 1
13 40400881 HOSE, 4(3/4-16UNF) x BENZO(PF3/8) 1500L(3/8) 1
14 40228731 BENZO BOLT, PF3/8 2
15 40228654 BONDED SEAL, 3/8" 4
16 40375341 T-LINE PIPE, PF3/8 x PT1/2 1
17 40230970 DUST PLUG, 1/2 MALE WHITE 1
18 40228697 CABLE TIE, 270mm 5
19 40228698 CABLE TIE, 540mm 2
20 40228758 TEFLON TAPE 1
21 40404049 DECAL-CAUTION 1
- 83 -
