IMBH61. HYDRAULIC LINE
NO. PART NO. DESCRIPTION Q'TY I.C. SERIAL OR DATE
1 40434301 BRACKET 1
2 40434302 NIPPLE, PT1/2 x 3/4-16UNF,HOSE 1
3 40230968 QUICK COUPLER, PT1/2 FEMALE 2
4 40401016 DUST PLUG, 1/2 MALE RED 1
5 40434303 HOSE, 4(3/4-16UNF) x BENZO(PF1/2) 1800L(3/8) 1
6 40400884 BENZO BOLT, PF1/2 1
7 40228653 BONDED SEAL, 1/2" 2
8 40434304 HOSE, 4(3/4-16UNF) x BENZO(PF3/8) 1050L(3/8) 1
9 40228731 BENZO BOLT, PF3/8 2
10 40228654 BONDED SEAL, 3/8" 4
11 40434305 NIPPLE, PT1/2 x 3/4-16UNF,HOSE 90° 1
12 40230967 QUICK COUPLER, PT1/2 MALE 1
13 40381095 DUST CAP, 1/2 FEMALE RED 1
14 40375341 T-LINE PIPE, PF3/8 x PT1/2 1
15 40230970 DUST PLUG, 1/2 MALE WHITE 1
16 40228697 CABLE TIE, 270mm 5
17 40228698 CABLE TIE, 540mm 2
18 40228758 TEFLON TAPE 1
- 85 -
